Description
These components connect a socket and running blade (KATANA) for BK prosthesis. This unique feature is designed to enable prosthetists to adjust the alignment easily using Hex wrenches as you do for normal prostheses. The adaptor is attached on the back of the socket, so that you can put this on the user who may have clearance issues.
 |
SP0200 Anchor A lamination lock is set at the rear of the trans tibial socket for a base for installing “SP0300 Abutment”. |
 |
SP0300 Abutment (8° . 15°) This is the abutment designed to connect to “SP0200 Anchor” in order to connect either the “SP0400 Initial Fitting Plug Connector” or “SP0401 Plug Connector.” This part can be connected with either the SP0400 or SP0401 for alignment. This comes in two initial angles of 8 and 15 degrees. |
 |
SP0400 Initial Fitting Plug Connector The plug connector is used for initial fitting. The SP0400 allows the “SP1100 Sport Recreational Foot”, to be pinched back and forth, a length of the prosthetic limb can be slid up and down for adjustment. This plus connector can be connected with the “SP0300 Abutment” for alignment. |
 |
SP0401 Plug Connector After completion of initial fitting, the SPO401 Plug Connector is replaced with the “SP0400 Initial Fitting Plug Connector” for connection to the foot. |
 |
SP1000 L-Shaped Plate (0° . 8° . 16°) The L-Shaped Plate is used for the knee disarticulation prothsis and the trans femoral prosthesis. An “M Socket Base with Screw” can be connected to the top of the plate. This comes in three initial angles of 0, 8 and 16 degrees. |
Warranty: 1 year
